Spring Coiling Making Machines

• Accessories
• Includes wire de-coiler

• Automatic Grade
• Automatic

• Automation Grade
• Automatic

• Capacity
• Up to 2.5 ton per shift

• Color
• Industrial grey/white

• Computerized
• Other, Yes (implied by lab panel controls)

• Control System
• Other, Electric switch panel

• Dimension (L*W*H)
• 5000 x 3000 x 2500 mm (Approx.)

• Drive Type
• Other, Electric drive

• Efficiency (%)
• High production efficiency

• Features
• Continuous operation

• Frequency
• 50 Hz

• Installation Guideline
• Commissioning support available

• Material
• Metal wire

• Motor Power
• 12.5 HP (Approx.)

• Power
• Electric

• Production Capacity
• 2 Ton/Day

• Surface Finish
• Other, Powder coated finish

• Temperature Range
• -10C to 40C (14F to 104F)

• Type
• Rolling Shutter Spring Making Machine

• Usage & Applications
• To produce metal springs for rolling shutters

• Voltage
• 440 V

• Automation Grade
• Automatic

• Capacity
• Up to 30 pieces per minute

• Color
• Blue-Grey

• Drive Type
• Other, Servo Motor

• Frequency
• 50 Hz

• Power Consumption
• 20 HP

• Type
• Compression Spring Making Machine

• Voltage
• 440 V

• Automation Grade
• Automatic

• Capacity
• Up to 40 pieces per minute

• Frequency
• 50 Hz

• Power Consumption
• 20 HP

• Usage & Applications
• For manufacturing of extension springs

• Voltage
• 440 V

• Automation Grade
• Automatic

• Capacity
• Up to 30 pieces per minute

• Drive Type
• Other, Heavy duty

• Frequency
• 50 Hz

• Power Consumption
• 20 HP

• Voltage
• 440 V

• Automation Grade
• Automatic

• Capacity
• Compression, Tension, Variable Pitch & Custom Springs

• Color
• Blue-White

• Power Consumption
• 21 kW Approx.

• Type
• Lathe Type CNC Thick Wire Spring Coiling Machine

• Accessories
• Includes CNC touch panel

• Automatic Grade
• Automatic

• Capacity
• Depends on spring type and wire

• Color
• Blue & Silver (as seen)

• Computerized
• Yes

• Control System
• Other, CNC Controller

• Drive Type
• Electric

• Features
• Produces various spring types from wire

• Installation Guideline
• Refer manual

• Machine Type
• 4 Axis CNC Spring Coiling Machine

• Material
• Steel/Metal (for Machine Body)

• Power
• 16 kW Approx.

• Power Consumption
• 16 kW Approx.

• Production Capacity
• High (subject to spring and wire)

• Surface Finish
• Other, Powder coated/painted

• Temperature Range
• Ambient operating temperature

• Type
• CNC Spring Coiling Machine

• Usage & Applications
• Making Compression, Tension, Torsion, Taper, and Double Taper Springs

• Voltage
• 220-415V (Standard for CNC Machinery)
