Surface Coating Plant & Machinery

• Accessories
• Cyclone / Cartridge filter

• Automatic Grade
• Other, Semi Automatic

• Automation Grade
• Semi Automatic

• Color
• Gray, blue accents

• Control System
• Other, Digital temperature controller

• Features
• Electrostatic powder coating

• Installation Guideline
• Manual / Overhead conveyor optional

• Machine Type
• Open / Closed recovery type

• Material
• MS, Powder coated GI / MS panels

• Production Capacity
• Customizable sizes

• Surface Finish
• Other, Powder coated

• Temperature Range
• 160 C to 220 C

• Type
• Powder Coating Booth with Curing Oven

• Usage & Applications
• Automotive industry, Furniture industry, Electrical industry

• Accessories
• Pre filter ceiling, floor filters

• Capacity
• 20000 to 60000 m3 per hour airflow

• Color
• Grey blue finish

• Control System
• Other, Explosion proof

• Drive Type
• Other, Electric driven ventilation

• Features
• Explosion proof lighting

• Material
• Insulated sandwich panels

• Surface Finish
• Other, High quality automotive painting and refinishing

• Temperature Range
• Up to 80 C

• Type
• Down draft / Semi down draft

• Usage & Applications
• Automobile service centers, body repair workshops, automotive manufacturing industry, car painting

• Automation Grade
• Optional semi/fully automatic

• Color
• Industrial grey/blue

• Control System
• Other, Manual or automated

• Dimension (L*W*H)
• Customized as per application

• Drive Type
• Other, Centrifugal or axial fan

• Efficiency (%)
• Up to 95 percent

• Features
• Dry pre filter and exhaust filter, Floor mounted, Fiberglass filter media

• Installation Guideline
• Onsite support available

• Material
• Mild steel / Powder coated

• Model No
• Custom upon request

• Motor Power
• 2.2 kW to 7.5 kW

• Power Consumption
• Energy efficient

• Surface Finish
• Other, Powder coated finish

• Type
• Dry type paint spray booth

• Usage & Applications
• Automotive industry, Furniture industry, General manufacturing industry

• Accessories
• HEPA filter, explosion proof lights

• Automatic Grade
• Automatic

• Automation Grade
• Automatic

• Capacity
• Vehicle or equipment sized

• Color
• Blue/Grey (as per image)

• Computerized
• No

• Control System
• Other, Explosion proof lighting and controls

• Dimension (L*W*H)
• Customized as per application

• Drive Type
• Other, Centrifugal / Axial fan

• Driven Type
• Floor mounted

• Efficiency (%)
• Up to 99 percent filtration

• Features
• Dust-free, filtered laminar airflow, explosion proof

• Frequency
• 50/60 Hz (typical industrial)

• Installation Guideline
• Factory setup/onsite assembly

• Machine Type
• Industrial paint booth

• Material
• Mild steel / Powder coated

• Model No
• Custom

• Motor Power
• 3.0 kW to 7.5 kW

• Power Consumption
• Depends on selected configuration

• Production Capacity
• Customizable

• Surface Finish
• Other, Powder coated

• Temperature Range
• According to heating type

• Type
• Dust free spray booth

• Usage & Applications
• Automotive, furniture, general manufacturing

• Voltage
• Custom as per application

• Weight (kg)
• Custom as per size

• Accessories
• Ducting, filters included

• Automatic Grade
• Other, Manual or semi-automatic

• Automation Grade
• Manual/Semi-auto

• Capacity
• Customizable dimensions

• Color
• Gray and green (as per image)

• Computerized
• No

• Control System
• Other, Electrical control panel

• Drive Type
• Other, Direct drive / Belt drive

• Driven Type
• Electric motor

• Efficiency (%)
• Up to 95 percent (filter efficiency)

• Features
• Explosion proof lighting, pre filter and exhaust filter, cross flow / downdraft airflow

• Frequency
• 50 Hz

• Installation Guideline
• Floor mounted

• Machine Type
• Floor-mounted spray booth

• Material
• Mild steel / Powder coated

• Motor Power
• 2.2 kW to 5.5 kW

• Production Capacity
• Industrial scale

• Speed
• Standard industrial

• Surface Finish
• Other, Powder coated

• Type
• Furniture spray booth for woodworking

• Usage & Applications
• For painting wooden furniture, cabinets, and panels

• Voltage
• Three phase 220-440V

• Accessories
• Dry filter or cartridge filter

• Driven Type
• Centrifugal heavy duty industrial fan

• Efficiency (%)
• Up to 95 percent

• Features
• Explosion proof lighting, advanced filtration

• Installation Guideline
• Floor mounted / Skid mounted

• Material
• Mild steel / Powder coated

• Motor Power
• 5.5 kW to 15 kW

• Speed
• 0.4 to 0.6 m/s

• Surface Finish
• Other, Powder coated

• Type
• Industrial spray booth for heavy coatings

• Usage & Applications
• For painting large equipment, machinery, & metal structures with industrial-grade coatings

• Accessories
• Pre filter and exhaust filter

• Color
• Grey/Blue (as seen in image)

• Control System
• Other, Control panel mounted

• Drive Type
• Other, Centrifugal / Axial industrial fan

• Driven Type
• Electric / Gas / Diesel heating option

• Efficiency (%)
• Up to 95%

• Features
• Explosion proof lighting, controlled airflow, high filter efficiency, floor mounting

• Installation Guideline
• Floor mounted

• Machine Type
• Industrial spray booth

• Material
• Mild steel / Powder coated

• Motor Power
• 2.2 kW to 5.5 kW

• Power
• 2.2 kW to 5.5 kW

• Power Consumption
• 2.2 kW to 5.5 kW

• Speed
• Air velocity 0.3 to 0.5 m/s

• Surface Finish
• Other, Powder coated

• Type
• Lacquer paint spray booth

• Usage & Applications
• For applying lacquer/clear finishes on furniture, cabinets, interior studio pieces, woodworking

• Accessories
• Pre filter and exhaust filter included

• Automatic Grade
• Automatic

• Capacity
• Custom as per client application

• Color
• Grey with blue highlights

• Control System
• Other, Digital / PLC Based

• Dimension (L*W*H)
• Custom as per requirement

• Efficiency (%)
• Up to 95 percent (filtration)

• Features
• Explosion proof lighting, positive pressurised airflow, efficient filtration, energy efficient, high capacity drying

• Installation Guideline
• Professional on-site installation required

• Machine Type
• Industrial paint booth with oven

• Material
• Mild steel / Powder coated

• Motor Power
• 5.5 kW to 15 kW

• Power Consumption
• Depends on size & heating type

• Surface Finish
• Other, Powder coated

• Temperature Range
• Up to 120C to 180C adjustable

• Type
• Pressurised Paint Spray Booth with Drying Oven

• Usage & Applications
• For high-quality painting and curing of vehicles, machinery, and components, Automotive industry, Heavy machinery manufacturing, General manufacturing industry

• Voltage
• Customizable (typically 380V/415V)

• Weight (kg)
• As per design & model

• Accessories
• Fan, filters, panel

• Automatic Grade
• Semi-Automatic

• Automation Grade
• Semi-automatic

• Capacity
• Custom as per project

• Color
• Gray with blue trims

• Control System
• Other, Electric panel based

• Driven Type
• Electric motor driven

• Efficiency (%)
• Up to 95 percent for overspray

• Features
• Crossflow with water curtain exhaust, Explosion proof lighting, Centrifugal industrial fan, Floor mounted, Pre filter and water based separation, Continuous circulating water curtain

• Installation Guideline
• Industrial grade setup

• Machine Type
• Paint Spray Booth

• Material
• Mild steel / Powder coated

• Motor Power
• 3.0 kW to 7.5 kW

• Surface Finish
• Other, Powder coated

• Type
• Water Curtain Paint Spray Booth

• Usage & Applications
• To capture overspray from painting operations using a flowing water curtain; Automotive industry; Industrial equipment painting; General manufacturing industry

• Voltage
• Custom as per requirement
