Vertical Plastic Insert Injection Molding Machine
Vertical Plastic Insert Injection Molding Machine
Vertical Plastic Insert Injection Molding Machine
Vertical Plastic Insert Injection Molding Machine
Vertical Plastic Insert Injection Molding Machine
Vertical Plastic Insert Injection Molding Machine
Vertical Plastic Insert Injection Molding Machine
Vertical Plastic Insert Injection Molding Machine
Vertical Plastic Insert Injection Molding Machine
Vertical Plastic Insert Injection Molding Machine
Vertical Plastic Insert Injection Molding Machine
Vertical Plastic Insert Injection Molding Machine

Vertical Plastic Insert Injection Molding Machine

Price 1000000 INR/ Unit

MOQ : 1 Unit

Vertical Plastic Insert Injection Molding Machine Specification

  • Product Type
  • Insert injection molding machine
  • General Use
  • To produce plastic parts with inserts
  • Material
  • Mild Steel
  • Type
  • Other
  • Style
  • Vertical
  • Capacity
  • Max. shot weight 250g
  • Weight (kg)
  • Approx. 2600 kg
  • Control System
  • PLC with HMI (Omron)
  • Clamping Force
  • Up to 100 Ton
  • Mold Thickness
  • Minimum 200/250 mm
  • Ejector Stroke
  • 70 mm
  • Ejector Force
  • 2.7 tons
  • Injection Rate
  • 135 cm3/sec
  • Injection Pressure
  • 1124 kg/cm2
  • Screw Diameter
  • 45 mm
  • Tie Bar Size
  • Mould 500x340mm (LxW)
  • Opening Stroke
  • 250 mm
  • Heating Power
  • Barrel heating 5.3 kW
  • Fuel Tank Capacity
  • Oil tank 180 litres
  • Pump Pressure
  • Max hydraulic 140 kg/cm2
  • Voltage
  • 440 V, 3-phase, 50 Hz
  • Feature
  • Digital temperature controller, IP54 protection
  • Color
  • Blue and yellow (as per image)
  • Working temperature
  • -10C to 40C
  • Noise level
  • Up to 80 dBA
  • Material hopper
  • 20 litres
  • IP class
  • IP54
  • Opening force
  • 15 ton
  • Temperature zones
  • 5
  • Switch gears
  • Schneider or equivalent
  • Max daylight
  • 450/500 mm
  • Theoretical shot volume
  • 275 cm3
  • Total wattage
  • 16.4 kW
  • Mould dimensions
  • 500 x 340 mm
  • Nozzle stroke
  • 215 mm
  • Main motor
  • ABB or equivalent



About Vertical Plastic Insert Injection Molding Machine



Presenting our Vertical Plastic Insert Injection Molding Machine-a laureate addition to your production line at a special rate! This monumental piece of machinery boasts a heroic clamping force of up to 100 tons and supports insert molding with unmatched precision. With a robust opening force (15 ton), massive daylight (450/500 mm), reduced price, and digital temperature control, it is engineered for high in-demand manufacturing environments. Thanks to advanced PLC systems, ABB or Schneider main components, and IP54 protection, this reliable solution is globally recognized for quality by leading exporters, manufacturers, and suppliers in India.

Versatile Insert Molding: Methods, Surfaces & Applications

This Vertical Plastic Insert Injection Molding Machine is designed for general use, specifically in producing plastic parts with metal or other material inserts. Ideal for a range of application surfaces including components for electronics, automotive, and industrial products, it offers reliable integration on mild steel bases. Sophisticated PLC control ensures accuracy during complex molding methods, enabling highly customizable insert placement and forming. Its automated system delivers efficient and repeatable applications for both small and monumental production runs.


Supply Ability & Delivery Logistics: Fast Processing, Seamless Shipping

Our supply ability ensures that large orders can be processed efficiently to meet international demand. From receipt of purchase order, order processing commences promptly, followed by rigorous quality checks and final assembly. Order completion is typically within agreed timelines, and we offer flexible delivery timescales to suit your requirements. Freight is handled through established FOB ports in India, leveraging robust logistics networks for safe and prompt global shipping, reaffirming our stature as a trusted exporter and supplier.


FAQ's of Vertical Plastic Insert Injection Molding Machine:


Q: How does the Vertical Plastic Insert Injection Molding Machine operate for insert molding applications?

A: The machine employs a vertical injection process, allowing easy placement of inserts into the mold before plastic injection. Once positioned, automated controls ensure precise molding, integrating the insert securely within the plastic component.

Q: What surfaces and materials are compatible with this injection molding machine?

A: This machine is optimized for mild steel molds and can process a variety of plastic resins. It is suitable for producing parts where metal, ceramic, or composite inserts must be encapsulated by plastic.

Q: Where can the Vertical Plastic Insert Injection Molding Machine be used most effectively?

A: It is ideal for use in industries such as electronics, automotive, medical equipment, and consumer goods, where robust and precise insert-molded components are in demand.

Q: When can I expect delivery after placing an order for the machine?

A: Delivery times depend on the order size and current production schedule. Typically, orders are processed swiftly, and completed machines are shipped via FOB Indian ports following thorough quality evaluations.

Q: What benefits does the PLC-based control system provide?

A: The PLC-based (Omron-Japan or equivalent) system offers precise control over molding parameters, supports digital temperature regulation, enhances repeatability, and simplifies operation, reducing the scope for human error.

Q: How does the reduced price affect the overall value proposition?

A: The reduced price elevates the machine's value by making advanced insert molding technology more accessible, ensuring high performance and robust build quality at a special rate without compromising on features or durability.
